DIEHL - TFM-68, ...4” x 8” 6-Head High Speed Jointed Moulder
6-Head (B-R-L-R-T-B) with 8-5/8" x 4-1/2" capacity. Head sequence: Bottom 15 HP, Right 10 HP, Left 10 HP, Right 10 HP, Top 15 HP, and Bottom 20 HP motor.
1st Bottom and 1st right side run at 3,600 RPM; all the other spindles run at 6,000 RPM utilizing the included Frequency Changer. Side heads tilt 35° inward and 5° outward.
Specifications:
Spindle diameter: Vertical 1-13/16"; Horizontal 2-1/8" dia. for top spindle only.
Built-in straight & profile jointers on spindles 2 - 3 - 4 & 5.
Variable feed speed from 20 - 150 FPM via 15 HP feed drive.
Cardan Shaft driven.
WAXLIT Pump and groove bed with groove cutters for 1st bottom.
Air chipbreakers and feed roll tensioning.
Starting panel and transformer included.
Weight: Approx. 14,000 Lbs
|
